| Model | CVDL13U | CVDL15U | | Display Technology | 3LCD | | Native Resolution | WUXGA 1920* 1200 | | Max. Video Input | 4K | | Brightness | 13000 ansi Lumens | 15000 ansi lumens | | Contrast | 100000:1 Contrast Ratio | | Fan Noise | As low as 27 dBa | | Aspect Ratio | 16:10 Native,16:9 Compatible | | Projection Method | Front, Rear,Ceiling,Table Top;Projection Image support horizontal and vertical flip | | Weight | 30 kg | | I/O Connectors | VGAx1; Y, Pb/Cb, Pr/Crx1; S-Videox1; HDMI⑤x2; DVIx1; CVBSx1; HDBaseTx1; IRx1; RS232x1; RJ45x1 | | Maximum Resolution | 4K via HDMI Terminal | | Computer Compatibility | Standard 1080P(1920x1080),WSXGA+,WXGA+,WXGA(1280x800/1280x768),UXGA, SXGA, XGA, SVGA, VGA, Mac… | | Video Compatibility | PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080P, 720p) | | Displayable Colours | 1.07 Billion | | Lens shift |
| U/D -40%to 120%; L/R 20% | | Lens Optional |
| Short throw lens,Long throw lens,Ultra-short focal-lens,360-degree wide-angle lens,Spherical Fisheye lens | | Throw Ratio | 1.46-2.95:1(STD) | | Projection Screen Size | 100" at 2.94m | | Projection Distance | 1.025-25.48m(Standard Power Lens ) | | Lamp Type/Lamp Life | 850W Roller type laser light source, 20000 hours life | | Keystone Correction * | ± 40° Vertical ± 30° Horizontal | | Dimensions (W x D x H) | 560x558x295 mm | | Remote Control | Full function remote with direct source selecting | | Power Supply | 100-240V, 50-60Hz | | Power Consumption | 1088W | | Operating Conditions | 5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m | | Uniformity | 90% | | Standard Accessories | AC Power Cord,VGA Cable, Remote Control,Quick Start Card,CD User Manual, Warranty Card | | Optional Accessories | Ceiling Mount Kit, Additional Ultra long Cable | | Guarantee | Projector 5 years |
Outstanding Features | ● 15,000 ANSI Lumens bright, with 90% uniformity and a 100000:1 Contrast Ratio. ● 3LCD imaging for rich, color saturated computer and video projection. ● 24*7 hrs long time working without problem. ● No weaken on brightness after 3 years usage. ● Optional wide-angle and telephoto lenses. Instant lens change system. ● 1 seconds for turn on the projector,fast then other type in this area. ● Includes most professional input configurations, including BNC and DVI. ● Vertical and Horizontal power lens shift and digital keystone correction. ● 16-bit color reproduction for superior color reproduction. ● Native WUXGA resolution. Compatible with inputs up-to 4K Support by HDMI. ● Variable Power Management option. Optional local or remote keylock. ● Custom warm-up screen option. Built-in Color Auto Picture Control. ● Built-in network(RJ45) monitoring and control. Optional network content delivery. ● 5 year projector warranty! |
|
